NetAttest EPS
Network Access Control with minimal impact to IT and superior user experience
All-in-one appliance
- Conducts user requests to access company’s resources and provides authentication, authorization, and accounting (AAA) services.
- The build-in RADIUS server provides multiple EAP authentication methods including MAC address, One-Time Passwords (OTP) or certificate-based authentication, etc.
- Acts as a dedicated certificate authority (CA) issuing and managing certificates. It can also act as a subordinate CA which integrates into an existing Public Key Infrastructure (PKI).
IEEE 802.1X WLAN access control
With the NetAttest EPS network administrators can manage the access to the WLAN securely. Guests, temporary employees or contractors can use the selfservice portal to request temporary access to the WiFi. When authenticated the guest user is automatically directed to the right network resources. The NetAttest EPS also provides an internal user database for storing temporary employees or contractors.
Easy to back-up and restore
Back-up takes less than 20 seconds and a full restore approximately 100 seconds. The full restore includes the CA function and the RADIUS function.
Easy to make redundant installations
In case of a redundant configuration the RADIUS server on both units are active. The network access servers require configuration to use the first NetAttest EPS unit as the primary RADIUS server and the second unit as the secondary RADIUS server. The full configuration, including the CA configuration, is automatically shared daily. In case the master CA crashes, the backup CA will take over.
Soliton Key Manager - issue and renew certificates in just 3 steps
The Soliton Key Manager app makes it easy for network administrators to use short-life certificates for enhanced security. The application offers a user-self-service to automatically request and install user- and device certificates on any device in just 3 steps. The Soliton Key Manager app sends the user a warning to renew the certificates upon users click the link to renew the certificate.
Other key benefits include:
- Soliton Key Manager adds security to the Simple Certificate Enrolment Protocol (SCEP) by including a unique secret per request and e.g. APID, IMEI, or UDID during the SCEP process.
- Soliton Key Manager can generate, if required, both a public and a private key. It stores the private key on the device in a format that cannot be exported while the public key is being forwarded to the NetAttest EPS where it is used for authentication purposes
Certificate Authority
- Web-portal: A self-service portal for end-users to request and download their own user and/or device certificate. Certificates are issued automatically or after approval by the administrator.
- Online Certificate Status Protocol (OCSP) Responder: The CA extended option offers OCSP-Responder for easy checking of revocation of certificates.
- Support of Simple Certificate Enrolment Protocol (SCEP): The embedded SCEP-server makes the issuing of digital certificates simple and scalable for other IT systems, such as MDM systems or third-party devices, that require a certificate for authentication.
- Customizable Certificate Signing Request (CSR) templates: The CSR templates include any kind of data of extended key usage and key generation such as certificate validity period and renewal period.
- Special-purpose certificates: The CA extended option allows the administrator to generate special purpose certificates such as Windows SmartCard, Code Signing and Domain Controller certificates.
MAC address authentication
With the MAC address feature embedded administrators have a dedicated database available that allows the authentication of MAC addresses of non-802.1X supplicants. The database can store up to 200,000 MAC addresses.
Other features include:
- The MAC address feature automatically detects the non-IEEE 802.1X supplicants in the network and adds them to the whitelist.
- The dedicated interface for the registration of new MAC-addresses allows the administrator to quickly add new devices to the network.
Unified deployment process
The NetAttest EPS-ap provides a unified deployment process, through the Soliton Key Manager (SKM), for distributing and installing digital certificates on any device and platform. The deployment process is always the same regardless the device and its operating systems.
Other key features:
- Proxy-server: Handles SCEP requests and adds additional security by protecting the internal Certificate Authority (NetAttest EPS) by URL rewriting and forwarding an SSL/TLS encrypted SCEP request to the internal Certificate Authority (NetAttest EPS).
- OTA protocol: Embeds the Apple Over-The-Air (OTA) protocol supporting certificates on Apple devices.
MDM option
For additional security the NetAttest EPS-ap provides a set of Mobile Device Management (MDM) features. It allows to create a profile including several MDM functions such as the automatic locking after a predefined time and the prerequisites of defining the password. Other functions include remote device lock and wipe and the possibility to obtain device information.
SPECIFICATIONS NETATTEST EPS
| EPS-SX15-A & EPS-SX15-V | EPS-ST05-A & EPS-ST05-V | EPS-DX05-A &EPS-DX05-V | ||
|---|---|---|---|---|
| Max. number of user registration | 200 | 200 / 500 / 2,000 / 5,000 | 100,000 | |
| Max. number of RADIUS clients | 20 | 500 | 1,000 / 2,000 | |
| Supporting authentication protocol | EAP-TLS, EAP-MD5, EAP-PEAP (MS-CHAPv2, GTC), EAP TTLS (PAP, CHAP, MS-CHAP, MS-CHAPv2, GTC), Cisco LEAP, EAP-FAST, PAP, CHAP, MS-CHAP, MS-CHAPv2 | |||
| Redundancy |  |  | | |
| RADIUS EXTENSION | One Time Password | | | |
| MAC address authentication option | | | | |
| Group profile | | | | |
| Certificate Authority (CA) | Client certificate publish | | | |
| External server certificate publish | | | | |
| Max. number of certificates | | 400/1,000/4,000/10,000 | 200,000 | |
| Extended CA function | | | | |
| External database | Windows Domain | | | |
| database | External LDAP database | | | |
| RADIUS proxy | | | | |
| Log manage- ment | RADIUS accounting | | | |
| manage- | RADIUS detail accounting | | | |
| ment | Log maintenance | | | |
| Other | SNMP (agent), NTP synchronisation, Syslog (TCP/UDP), Support UPS | SNMP (agent), NTP synchronisation, Syslog (TCP/UDP), Support UPS | SNMP (agent), NTP synchronisation, Syslog (TCP/UDP), Support UPS | |
| EPS-SX15-A | EPS-ST05-A | EPS-DX05-A | |
|---|---|---|---|
| Form Factor | Desktop (option rack mount kit) | EIA19 inch (incl. rack mount kit) | EIA19 inch (incl. rack mount kit) |
| Dimensions (W x D x H) | 165 x 43 x 106 mm | 438 x 44 x 292 mm | 443 x 44 x 386 mm |
| Network interface | 10/100/1000BASE-T(X) Auto-MDI-X x 4 ports | 10/100/1000BASE-T(X) Auto-MDI-X x 4 ports | 10/100/1000BASE-T(X) Auto-MDI-X x 4 ports |
| Weight | 0.65 kg | 4.2 kg | 7.3 kg |
| Power supply | 90 ~ 264VAC 47 ~ 63Hz (90 ~135Vac) | 90 ~ 264VAC 47 ~ 63Hz (90 ~135Vac) | 90 ~ 264VAC 47 ~ 63Hz (90 ~135Vac) |
| Max. power consumption | 22 VA | 28 VA | 120 VA |
| Calorific value | 75BTU/h 18.9kcal 22W | 95.5BTU/h 24.1kcal 28W | 409.2BTU/h 103.1kcal 120W |
| Operating environment | Temperature 0 ~ 40°C Humidity 20 ~ 90% non-condensing | ||
| Certifications | VCCI (Class B) FCC (Class B) CE, UL, RoHS PSE (power adapter) | VCCI (Class A) FCC (Class A) CE, UL, RoHS PSE (power cable) |
| EPS-SX15-V | EPS-ST05-V | EPS-DX05-V | |
|---|---|---|---|
| Supporting virtual platform | VMware ESXi 6.7 / 6.5 / 6.0 | ||
| VMware virtual machine version | 10 | ||
| Virtual machine image | OVA | ||
| Number of CPU | 2 | 4 | 4 |
| Memory size | 2,048 MB | 8,192 MB | |
| HDD 1 | 2GB | 5GB | 96GB |
| Network adapter | 4 |
- Supports redundancy with virtual and physical appliance.
- Support back-up/restore between virtual and physical appliance
- No support for displacement by using virtual platform function such as Vmotion and VMwareFT (use the NetAttest EPS redundancy function)
| MODEL | OPTION LICENSE | DESCRIPTION | |
|---|---|---|---|
| OP1 | EPS-ST05 | User extended option (500) | • Extend maximum number of user registration |
| OP2 | EPS-ST05 | Function extended option (2,000) | • Extend maximum number of user registration • Enable Windows Domain authentication • Group Profile |
| OP3 | Function extended option (5,000) | ||
| OP4 | EPS-SX15 | Windows Domain option | • Enable Windows Domain authentication |
| OP5 | EPS-DX05 | RADIUS Client extended option | • Extend maximum number of RADIUS Client |
| OP6 | EPS-DX05 | MAC Address extended option | • Enable MAC Address authentication with dedicated DB (maximum 200,000 addresses are registrable) |
| OP7 | EPS-ST05 | ||
| OP8 | EPS-SX15 | ||
| OP9 | EPS-DX05 | CA Extended option | • Enable certificate distribution by Web enroll • Enable certificate distribution by SCEP enroll • Enable publishing Windows Smart Card logon certificate • Execute certification profile |
| OP10 | EPS-ST05 | CA Extended option (200) | |
| OP11 | CA Extended option (500) * User extended option (500) is required to be purchased together | ||
| OP12 | CA Extended option (2,000) * Function extended option (2,000) is required to be purchased together | ||
| OP13 | CA Extended option (5,000) * Function extended option (5,000) is required to be purchased together | ||
| OP14 | EPS-DX05 | One-Time Password server option | • Enable One-Time Password function |
| EPS-ST05 | |||
| EPS-SX15 |
Key specifications Soliton KeyManager
Platform: Windows
Operating system version: Windows 10 /Windows 8.1 (Except RT)/ Windows 7SP1
Platform: Mac OS
Operating system version: 10.14 / 10.13
Platform: iOS/iPadOS
Operating system version: 13.2-13.1 / 12.4-12.0 / 11.4-11.0
Platform: Android
Operating system version: 9.0 / 8.1-8.0 / 7.1-7.0 / 6.0
* In Android 10, the certificate cannot be acquired due to the change of the OS specification.
Currently, the new version supporting Android 10 is in preparation. Please wait for the new version.
Download information Soliton Key Manager
Platform:Windows
- Updated: February 13, 2019
- Version: 2.0.1
- Size: 11MB
- SHA256：8D84062C6728ADFD93AEAD99130AE9FF9E1AF7DFABD62CB27661727F5FD90D3F
WHAT’S NEW：
support debug mode
Bug fixes
-Host name and port number can not be specified in custom setting
-During applying for renewal, operation (e.g. delete) of renewal source certificate can be done
-failing install for CA certificate of Multitage configuration
-other bugs
- Updated: July 31, 2018
- Version: 2.0.1
- Size: 7.2MB
- SHA256：9e59a668c983563c90a50159ad7654734889fac89ea3903522c0b371136791f0
WHAT’S NEW：
Multilingual
Bug fixes
Platform:iOS
Application can be downloaded from App Store
Platform:Android
Application can be downloaded from Google Play
SecureBrowser
SecureBrowser is a remote access solution that establishes connections between a remote device and web servers inside a network. The SecureBrowser can use the digital certificates issued by the NetAttest EPS for strong authentication purposes. Users can now only access the organisation’s web servers by using a username, password and a valid device certificate.
NetAttest LAP
Not all networks allow the use of IEEE 802.1X network control. Examples are branch offices without managed switches or network environments existing of non-IEEE 802.1X supplicants. Integration with the NetAttest LAP adds an additional layer of security to the network.
